型號 Type | 測量范圍mm Measuring Range mm | |
適用直徑 Applicable diameter | ≤精度 ≤Accuracy | |
CON1無尾架 | 3-35 | 0.002 |
CON4無尾架 | 1-35 | 0.002 |
CON2無尾架 | 10-50 | 0.002 |
CON3無尾架 | 20-102 | 0.004 |
Simple concentric measuring seat, high accuracy, easy to carry. It can be used with magnetic table holder measuring meter for rapid detection. At the same time, it can be installed on the workbench of projector and image analyzer to clamp and rotate measuring axles and cutting tools for visual jump measurement or appearance defect detection.
簡易同心測量主座，精度高，攜帶方便?？膳浜洗判员碜鶌A持測量表用于快速檢測。同時可安裝于投影儀、影像儀工作臺上，用于夾持、轉動測量軸類及刀具等產品，進行可視化中跳動測量，或者外觀缺陷檢測。
